Gear hobbing machine for high precision gears 546M

Gear hobbing machine for high precision gears 546M
Gear hobbing machine for high precision gears 546M
Send Inquiry
Product Code : 23
Brand Name : Kolomna / STANKO
Product Description

Gear cutter master machine is designed for fine cutting worm wheels of high precision; dividing wheels, ring gear, worm gear big size of gear milling machines; dividing wheels for faceplate for vertical turret lathe including C axis, positioning of the faceplate; dividing wheels of rotary tables including for table of jig boring machine; worm wheels of other dividing machines; wheels of astronomical instruments and parts

Specification

Gear hobbing machine for high precision gears 546M

  • work piece diameter 5000 x module 16 mm / STANKO
  • Work piece diameter, mm 2250-5000
  • Module 16
  • Number of teeth of the gear 120-800
  • Table diameter, mm 3800
  • Distance between centers axes of table and gear cutter, mm 1150-2700
  • Weight of work piece max, kg 40000
